Line Luxury stainless steel shower tray drain channel

The TECNOAGUA Line Luxury stainless steel built-in shower tray channel collects water across the length of the shower and features a decorative stainless steel finish. It includes a T-181L geotextile membrane for integration with the waterproofing system.

This range has an external width of 78 mm and a height of 65 mm. The Ø50 mm VH outlet and the 360° swivel elbow facilitate connection to the drainage pipework. It is available in seven lengths.

Features

• Line Luxury stainless steel drain grate.
• Ø50 mm VH outlet.
• 360° adjustable elbow.
• Geotextile sheet measuring 1,500 × 2,000 mm.
• External width: 78 mm.
• Height: 65 mm.
• Available lengths: from 350 to 950 mm.
• TECNOAGUA reference: T-181L.

Available dimensions

• Code 50123: 350 × 78 × 65 mm / Ø50 VH.
• Code 50124: 450 × 78 × 65 mm / Ø50 VH.
• Code 50125: 550 × 78 × 65 mm / Ø50 VH.
• Code 50126: 650 × 78 × 65 mm / Ø50 VH.
• Code 50127: 750 × 78 × 65 mm / Ø50 VH.
• Code 50128: 850 × 78 × 65 mm / Ø50 VH.
• Code 50129: 950 × 78 × 65 mm / Ø50 VH.

All dimensions include a 360° swivel elbow and a geotextile sheet measuring 1,500 × 2,000 mm.
